INSTALLATION
2.3.3
Sampling System Installation
To install the sampling system follow the steps below:
a.
Select a location close to the measurement point. The ambient temperature
should be within the range of -20 to 60°C (-4 to +140°F) (preferably 0
to +40°C (+32 to +104°F) for optimum performance). Consult Michell
for special heating or cooling options if the temperature is outside of this
range.
b.
Fasten the sampling system to a vertical surface or instrument stand
using the four M8 size mounting holes at each corner.
c.
Connect the sample inlet and outlet tubing to the fi ttings of the inlet/outlet
ports on the sampling system. If the sampling system has been ordered
from Michell, the fi tting is a 6mm or 1/4" Swagelok
Follow standard Swagelok
procedure.
NOTE: The sampling line between the process point and the sampling system
should be as short as possible to minimize the lag time.
14
HIGH PRESSURE! High pressure gases are potentially hazardous.
Energy stored in these gases can be released suddenly and with
extreme force. High pressure systems should be assembled and
operated only by people who have been trained in proper safety
installation instructions for the connection
®
Promet I.S. User's Manual
practices.
bulkhead union.
®
97221 Issue 5, March 2017
