OPERATION
• For the model with active pressure compensation (
pressure reading value will be automatically converted based on
the new unit selected.
• For the model without active pressure compensation (
manually set pressure value will NOT be automatically converted
based on the new unit selected. The value must be manually
changed. For example - if the pressure is set at 60 barg - when the
pressure unit is changed to
60 psig. This must be manually changed to 870 psig.
NOTE: The pressure fault alarm set point under
sub-menu - will also switch to the selected unit. The value will be automatically
converted based on the new unit selected.
3.5.2

Settings for the PPMV I (Ideal Gas) Reading

The resolution of PPMV I (ideal gas) readings can be adjusted between one decimal
point to three decimal points, based on the user's preference. It will not change the
resolutions of readings with other units.
a. Increase or decrease the resolution by pressing the  and  keys.
b. When the desired resolution is on the display, press the
display will change to the next setting parameter which is for setting the
scrolling intervals of the unit's full name on the Main Reading Page.
The PPMV I (ideal gas) readings at the Main Reading Page, if selected, will then
change to the set resolution.
3.5.3

Setting the Scrolling Interval for a Unit's Full Name

At the Main Reading Page, the full description of the currently selected unit will scroll
across the display on the bottom line at set intervals. This interval can be set to the
user's preference.
a. Increase or decrease the scrolling interval (in seconds) by pressing the
 and  keys.
b. When the desired value is on the display, press the
will then change to the next sub-menu
36
Promet I.S. User's Manual
, the value of the pressure setting will be
psiG
0. 1 2 3
P P M V _ I
1 0. 0
S C R O L L
– fault alarm settings.
FAULT
), the
P1/P2
), the
G
– fault alarm settings
FAULT
key. The
Select
key. The display
Select
97221 Issue 5, March 2017
