INSTALLATION
2.3.3
Sampling System Installation
To install the sampling system follow the steps below:
a.
Select a location close to the measurement point. The ambient temperature
should be within the range of -20 to +60°C (-4 to +140°F) (preferably
0 to +40°C (+32 to +104°F) for optimum performance). Consult Michell
Instruments for special heating or cooling options if the temperature is
outside of this range.
b.
Fasten the sampling system to a vertical surface or instrument stand
using the four M8 size mounting holes at each corner.
c.
Connect the liquid inlet and outlet tubing to the fi ttings of the inlet/
outlet ports on the sampling system. If the sampling system has been
ordered from Michell Instruments, the fi tting is a 6mm or 1/4" Swagelok
bulkhead union. Follow standard Swagelok
fi tting these unions.
NOTE: The sampling line between the process point and the sampling system
should be as short as possible to minimize the lag time.
14
HIGH PRESSURE! High pressure liquids are potentially
hazardous. Energy stored in these liquids can be released
suddenly and with extreme force. High pressure systems
should be assembled and operated only by people who have
been trained in proper safety practices.
Liquidew I.S. User's Manual
installation instructions when
®
97092 Issue 5.1, October 2018
®
