Korg Trinity Parameter Manual page 72

3–1: Key Zone
With a setting of 12, the volume will gradually increase until the key one octave above the Bottom
Key will sound at the original volume.
With a setting of 60, the volume will gradually increase until the key five octaves above the Bot-
tom Key will sound at the original volume.
3–1d: Bottom Key
Specifies the bottom key of the range in which timbres 1–8 will sound.
The key setting can also be input from the keyboard.
Page Menu Command
3–1A: Write Combination
This command writes an edited combination into the specified combination number. Be sure to
write important combinations. If you turn the power off or select another combination before writ-
ing, it will not be possible to recover the edited data.
For details refer to Basic Guide page 23, "9. Writing a program or combination".
64
Volume change as affected by keyboard position
Volume
Bottom
Slope
Bottom Key
[C–1...G9]
Key
Top
Slope
Top Key
