2–5: OSC EG (Oscillator Envelope Generator)
This page contains settings for the oscillator EG that creates time-variant changes in the pitch of
oscillators 1 and 2. The depth of the pitch change produced by this EG is adjusted in "2–1f(2–3f):
Oscillator EG."
2–5a
2–5b
2–5a: OSC EG
Makes Level and Time settings to specify how the pitch will change over time.
Level
The operation of this parameter depends on the setting of "2–1f(2–3f): Oscillator EG" Intensity. For
example with a setting of +12.00, a setting of +99 will raise the pitch one octave, and –99 will lower
the pitch one octave.
Start (Start Level)
Sets the pitch level at which the sound will begin at the time of Note-on.
Attack (Attack Level)
Sets the pitch level that will be reached when the Attack Time has elapsed.
Release (Release Level)
Sets the pitch level that will be reached when the Release Time has elapsed.
Time
Specifies the times over which the pitch will change.
Attack (Attack Time)
Sets the time from note-on until the pitch specified by the Attack Level is reached.
Decay (Decay Time)
Sets the time from when the Attack Level is reached until the normal pitch is reached.
Release (Release Time)
Sets the time from note-off until the pitch specified by the Release Level is reached.
Settings for time-variant pitch change (when EG Intensity = +12.00)
+99 = approximately one octave
0 = the pitch
reached when
the key remains
pressed
–99 = approximately one octave
2–5: OSC EG (Oscillator Envelope Generator)
Attack Level
Note-on
Start Level
Decay Time
Attack
Time
Page Menu
2–5A
2–5B
2–5C
[–99...+99]
[–99...+99]
[–99...+99]
Note-off
Time
Release Level
Release Time
[0...99]
[0...99]
[0...99]
