Korg Trinity Parameter Manual page 146

2–1: Filter, Protect & Data Dump
• Loading combination data from disk
If this is un-checked, internal combination memory can be written into.
Protect Song (Protect Song Memory)
This determines whether or not internal song memory will be protected. However when the
power is turned OFF, song data in internal song memory will be lost regardless of this setting.
If this is checked, internal song memory will be protected, and the following Write operations will
be prohibited.
• Sequencer recording
• Song data reception by MIDI data dump
• Loading song data from disk
If this is un-checked, internal song memory can be written into.
Page Menu Command
2–1A: Dump Program
2–1B: Dump Combination
2–1C: Dump Drum Kit
2–1D: Dump Global
2–1E: Dump Song
2–1F: Dump All
These commands transmit TRINITY data as a MIDI exclusive message to an external device, such
as another TRINITY series instrument, a MIDI data filer, or a computer.
While a Page Menu Command is displayed, data dumps can be transmitted and received regard-
less of the System Exclusive setting.
If you wish to transmit MIDI data (program or combination data) to another TRINITY series
instrument, set the Global MIDI channels of the two instruments to the same channel.
When transmitting MIDI data to a data filter, there is normally no need to match MIDI channels.
When you select a command (refer to the table below), a dialog box will appear.
If you have selected a command other than Dump All, select as necessary the bank and/or num-
ber of the data that you wish to dump, and press OK.
138
Dump Program Programs of all banks, programs of the specified bank, 1 program
Dump Combination Combinations of all banks, combinations of the specified bank, 1 combination
Dump Drum Kit All drumkits, 1 drumkit
Dump Global Global parameters
Dump Song All songs
Dump All Programs of all banks + combinations + drumkits + global parameters + songs
While Data Dump is being executed, be careful not to operate the switches or controls of the
TRINITY.
