1–2: Timb Param2 (Timbre Parameter 2)
Here you can make settings related to the output of each timbre.
Refer to "1–1:
Timb Param1"
Data for the
selected timbre
Timbre No.
1–2c
1–2d
1–2e
1–2f
1–2c: Pan (Panpot)
Specifies the pan for each timbre 1–8 (the rear panel output jacks 1/L/MONO and 2/R). If an
insert effect is being used, make the pan setting in "7–2: Insert Effects."
This parameter is also displayed in Combination Play mode "1–1: Combination Play" (
in this manual), and can be set from either location.
If "1–1d: Timbre Mode" is INT, receiving a Panpot message (CC#10) in Combination Play mode
will cause the pan setting to change. (However, only if this setting is L000–R127.)
1–2d: Volume
Specifies the volume for timbres 1–8.
This parameter is also displayed in Combination Play mode "1–1: Combination Play" (
in this manual), and can be set from either location.
If "1–1d" Timbre Mode" is INT, receiving a Volume message (CC#7) in Combination Play mode
will cause the volume setting to change.
If "1–1d: Timbre Mode" is EXT, the volume setting will be transmitted when you select a combina-
tion.
1–2e: Send 1
Specifies the send level (the input level to the master effects) for timbres 1–8. This will also deter-
mine the output level to the rear panel outputs 3 and 4.
If the TRINITY receives a MIDI Effect 3 Level message (CC#93) in Combination Play mode when
"1–1d: Timbre Mode" is INT, this setting will change. (But only if this parameter is set to 0–127.)
1–2f: Send 2
Specifies the send level (the input level to the master effects) for timbres 1–8. This will also deter-
mine the output level to the rear panel outputs 3 and 4.
If the TRINITY receives a MIDI Effect 1 Level message (CC#91) in Combination Play mode when
"1–1d: Timbre Mode" is INT, this setting will change. (But only if this parameter is set to 0–127.)
Page Menu Command
1–2A: Write Combination
This command writes an edited combination into the specified combination number. Be sure to
write important combinations. If you turn the power off or select another combination before writ-
ing, it will not be possible to recover the edited data.
For details refer to Basic Guide page 23, "9. Writing programs and combinations."
1–2: Timb Param2 (Timbre Parameter 2)
Page Menu
[OFF, L000...C064...R127, PROG]
[0...127, PROG]
[0...127, PROG]
1–2A
page 55
[0...127]
page 55
