ToneLab TT
CONTENTS
Circuit Diagram: Page 2-8
Structural Diagram: Page 9
Block Diagram: Page 10-12
Test Mode: Page 13
Calibration: Page 14
Parts List: Page: 15-17
2nd Edition
Issued date: November 28th, 2003
Issued by: KORG INC.
Advertisement
Related Manuals for Korg ToneLab TT
Summary of Contents for Korg ToneLab TT
- Page 1 ToneLab TT CONTENTS Circuit Diagram: Page 2-8 Structural Diagram: Page 9 Block Diagram: Page 10-12 Test Mode: Page 13 Calibration: Page 14 Parts List: Page: 15-17 2nd Edition Issued date: November 28th, 2003 Issued by: KORG INC.
- Page 4 X2540̲K2399B̲sch̲20030729.sch‑1 ‑ Tue Jul 29 10:45:40 2003...
- Page 5 X2540̲K2399B̲sch̲20030729.sch‑2 ‑ Tue Jul 29 10:47:20 2003...
- Page 6 X2540̲K2399B̲sch̲20030729.sch‑3 ‑ Tue Jul 29 10:48:45 2003...
- Page 7 X2540̲K2399B̲sch̲20030729.sch‑4 ‑ Tue Jul 29 10:49:40 2003...
- Page 8 X2540̲K2399B̲sch̲20030729.sch‑5 ‑ Tue Jul 29 10:50:25 2003 1SR-139-400 -> 1S4 lot B-10より自然切替...
- Page 10 X2540̲EBLK̲20030707.sch‑1 ‑ Wed Jul 30 14:49:03 2003...
- Page 11 X2540̲K2399B̲blk̲20030729.sch‑1 ‑ Tue Jul 29 11:00:14 2003...
- Page 12 X2540̲K2399B̲blk̲20030729.sch‑2 ‑ Tue Jul 29 11:01:04 2003...
- Page 13 ToneLab Test Mode How to start and operate the test mode (LINE/AMP switch must be set to AMP): TAP + PEDAL & POWER ON: Internal test, Operational part (knob, etc.) test TAP + REVERB & POWER ON: MIDI test, Audio test WRITE + 1 &...
- Page 14 CAB028(STEREO-MONO) Lch and Rch must be short-circuited...
- Page 15 PART CODE PART NAME NOTE Q'TY 001239600 PCB ASSY KLM-2396/2430 TONELAB M.PART 001239900 PCB ASSY KLM-2399/2414/27/28 M.PART 001242900 PCB ASSY KLM-2429 TONELAB M.PART 304000010 TR 2SA733A T K (TR) KLM-2399/2414/27/28 304000150 TR 2SC3327 A/B (TPE4) KLM-2399/2414/27/28 304050180 DIGITAL TR DTC144EKA T146 (TS) KLM-2399/2414/27/28 304050190 DIGITAL TR DTA144EKA T146 (TS)
- Page 16 PART CODE PART NAME NOTE Q'TY *304X254003 TR NPN 2SC2458 KLM-2399/2414/27/28 *312X254000 LED DISPLAY TOD-4201FMRL-B P KLM-2396/2430 *312X951G03 CHIP LED 12-21SRC/TR8 KLM-2396/2430 *313X254000 LCD DLC-90086N M.PART *315X150003 LED MSB31DA-1 KLM-2396/2430 *315X254000 DOUBLE DIODE DAN202U KLM-2396/2430 *315X254000 LED MAA4361F (ORANGE) KLM-2399/2414/27/28 *315X254001 DOUBLE DIODE DA204U KLM-2396/2430 *315X254002 DOUBLE DIODE DA227...
- Page 17 PART CODE PART NAME NOTE Q'TY *475X254003 HARNESS HNS-3267 BOARD IN KLM-2399/2414/27/28 *475X254004 HARNESS HNS-3268 BOARD IN KLM-2399/2414/27/28 *475X254005 HARNESS HNS-3269 BOARD IN KLM-2399/2414/27/28 *475X254006 HARNESS HNS-3270 BOARD IN KLM-2399/2414/27/28 *475X254007 HARNESS HNS-3271 BOARD IN KLM-2399/2414/27/28 *475X254008 HARNESS HNS-3272 BOARD IN KLM-2399/2414/27/28 *475X254009 HARNESS HNS-3274 KLM-2399/2414/27/28...
