3500 Series Flat Panel Industrial PC
Chapter Three - Installation
System Components
This section describes the components on the unit to help you locate features relevant
to installation.
3515 Front Panel
The 3515 comes with a NEMA 4/4X/12 and IP65 sealed front panel with a TFT (Figure
3-3) display. The panel protects the system's interior when the system is properly panel
mounted.
T OU CH
S CR E E N
(OP T IONAL )
12
I R
IR P OR T P OW E R DIS K COM INP U T
Figure 3-1. 3515 TFT Active Display Front Panel
POWER DISK
COM INPUT
P
O
R
T
