Xycom 3500 Series Manual page 24

3500 Series Flat Panel Industrial PC
Mount the front floppy and keyboard access kit to the plate or the panel as shown (3-12).
Torque the nuts to 35 in/lb. (3.95 Newton Meters).
The 3500 series supports one floppy drive. If you want to use the floppy
drive connector, the unit cannot have an internal floppy drive. (The ex-
ternal floppy's connector is mounted in the internal floppy bay.)
24
Figure 3-11. Front Mounted Connectors Cutout Dimensions
Figure 3-12. Front Floppy and Keyboard Access Option
Note
