External Floppy Connector - Xycom 3500 Series Manual

3500 Series Flat Panel Industrial PC

External Floppy Connector

This connector is only available if the unit is ordered without the internal floppy (since
the floppy interface supports only one floppy option).
70
Pin Signal
9 Fused VCC
10 ORB_GND
11 NC
12 DDCDAT
13 HSYNC
14 VSYNC
15 DDCCLK
Pin Signal
1 +5V
2 IDX
3 FDS1
4 +5V
5 NC
6 DCHG
7 NC
8 NC
9 GND
10 MO1
11 NC
12 FDIRC
13 NC
Pin Signal
14 FSTEP
15 NC
16 FWD
17 GND
18 FWE
19 GND
20 FTK0
21 GND
22 FWP
23 GND
24 FRDD
25 GND
26 FHS
