Chapter Two – Testing
On units with MS-DOS installed, diagnostic tests are provided as a tool to verify the op-
eration of system hardware functions. If any of these tests fails, either you do not have
the correct default setting or there is a failure. Check the default settings and run the tests
again. If another failure occurs, contact Xycom Automation's Product Repair & Cus-
tomization Department (see Chapter 5).
Remove any device drivers or memory resident programs (TSRs) in-
stalled on the system before running Xycom Automation diagnostic
tests. If you do not, unexpected failures may occur.
The diagnostic disk does not provide an option to test a CD-ROM drive.
Make sure the BIOS setup menus are configured properly (factory set configuration).
To enter the BIOS setup menus,
1. Press
2. Make the necessary changes by following directions on the screen.
3. Press
4. Press
Refer to your CPU manual for more information on the BIOS setup menus.

Preparing for the Tests

You need the following equipment to test your system:
•
Floppy disk drive
•
Xycom Automation System Test Disk (3.5-inch, DS/DD bootable disk, Xycom
Automation part number 99290-001)
•
Centronics-compatible printer cable
•
Parallel printer (Centronics-style interface)
•
Two serial loopback test connectors (refer to Figure 2-12-1 for pinouts)
•
Formatted 3.5-inch, DS/HD disk (1.44 MB)
•
IBM PC/AT or PS/2 compatible keyboard
after the POST RAM test has completed.
F2
ESC.
ENTER twice to save the settings and exit the BIOS setup menus.
Note
