Command
Information Requests (continued)
Query HDCP status of an
output
Query HDCP status of all
outputs
Query hardware status
Example:
KEY:
X@
= Output number: 1011 through 8994 (physical video connections on all chassis in the system) Response is four
digits with leading zeros. Example: 2994 = device 2, card 99, connector 4
X1)
= Hardware element status: 1 = On, 0 = Off.
X1@
= Internal temperature in degrees Celsius. Response is two digits with a leading zero.
X4%
= Output HDCP status
0 = No active sink device detected (unplugged)
1 = Sink detected, output not encrypted
2 = Sink detected, output encrypted with HDCP v1.n (plugged and encrypted)
IP Setup
NOTES:
•
Unless noted, all commands apply to LAN A.
•
After adjusting any IP setting, enter the network reboot command
Set unit name
24
NOTES:
•
Up to 15 characters are permitted.
•
No blank or space characters are permitted.
•
No distinction is made between upper- and lowercase.
•
The first character must be an alpha character (A-Z, a-z). The last character cannot be a hyphen.
View unit name
KEY:
X11@
= Unit name: Text string of up to 15 characters: A-Z, 0-9, and hyphen (-).
Quantum Ultra Videowall Processing System • Remote Configuration and Control
ASCII Command Response
(Host to Processor) (Processor to Host)
E X@ } X4% ]
O HDCP
In verbose modes 2 and 3:
HdcpO
E } X4%
OHDCP
In verbose modes 2 and 3:
HdcpO
X1)
S
<Primary PSU>, <redundant PSU>, <top fans>, <rear fans>, <temperature>
S Sts1 1 1 1 26
E X11@ }
CN Ipn •
E } X11@ ]
CN
In verbose modes 2 and 3:
Ipn •
Additional Description
View HDCP status
X@
X@ X4% ]
*
X4% X4% X4% ]
... View HDCP status
1 2 3
n
outputs from 1 through n.
X4% X4% X4% X4% ]
...
1 2 3 n
X1) X1) X1) X1@ ]
• • • •
View the status of the following
hardware elements in the order
shown below:
Status (verbose modes 2 and 3):
Primary power supply: 1 (on)
Redundant power supply: 1 (on)
Top fans: 1 (on)
Rear fans: 1 (on)
Temperature: 26 °C
E ]
1BOOT for the command to take effect.
X11@ ] Specify a name for the unit.
View the name of the unit.
X11@ ]
X4%
of output
.
X4%
of all
