5.2 Type Code String

Example of Drive Configurator interface set-up: The numbers shown in the boxes refer to the letter/figure number of the
type code string. Read from left to right.
Product
FCM 106 FCP 106 Product group
5 5
Table 5.1 Type Code Specification
56
®
VLT
Name
Series
Load profile, frequency converter
Power size
Mains voltage
Enclosure
RFI filter
Fan option
Special version
Options
Not assigned
Motor range
Efficiency class
Load profile, motor
Shaft power
Nominal motor speed
Motor mounting option
Motor flange
Danfoss A/S © 06/2016 All rights reserved.
DriveMotor FCP 106/FCM 106
Position Selection options
1–3 FCP
FCM
4–6 106
7 N: Normal overload
H: High overload
8–10 0.55–7.5 kW (K55–7K5)
11–12 T4: 380–480 V AC
13–15 C66: IP66/UL TYPE 4X (FCP 106 only)
C55: IP55/Type 12 (FCM 106 only)
16–17 H1: RFI filter Class C1
18 F: With fan
19–21 SXX: Latest release - standard software
22–23 ®
AN: VLT Memory Module MCM 101, without fieldbus
®
AM: VLT Memory Module MCM 101, VLT
24 X: Reserved
25 E: Standard motor range
26 2: Motor efficiency IE2
4: Motor efficiency IE4
27 N: Normal overload
H: High overload
28–30 0.55–7.5 kW (K55–7K5)
31–33 150: 1500 RPM
180: 1800 RPM
300: 3000 RPM
360: 3600 RPM
34–36 B03: Foot mounting
B05: B5 flange
B14: B14 Face
B34: Foot and B14 face
B35: Foot and B5 flange
37–39 000: Foot mounting only
085: Motor flange size 85 mm
100: Motor flange size 100 mm
115: Motor flange size 115 mm
130: Motor flange size 130 mm
165: Motor flange size 165 mm
215: Motor flange size 215 mm
265: Motor flange size 265 mm
300: Motor flange size 300 mm
350: Motor flange size 350 mm
®
PROFIBUS DP MCA 101
