Frequency Converter/Options Selections; Remote Mounting Kit; Local Operation Pad - Danfoss VLT DriveMotor FCP 106 Design Manual

System Integration
3.4 Frequency Converter/Options
Selections

3.4.1 Remote Mounting Kit

Illustration 3.8 Remote Mounting Kit Connections
62.5 + _ 0.2
1
1 Panel cutout. Panel thickness 1–3 mm (0.04–0.12
in)
2 Panel
3 Gasket
4 LCP
Illustration 3.9 Remote Mounting Kit Connector
MG03M202
Design Guide
1
2

3.4.2 Local Operation Pad

2
3
4
Danfoss A/S © 06/2016 All rights reserved.
Control panel
Panel door
Illustration 3.10 LCP Remote Mounting
Illustration 3.11 LOP Connections
42 mm
2
1
3
55
53
12
50
27
19
18
39
3
