Danfoss VLT DriveMotor FCP 106 Design Manual page 64

Specifications
E
6 6
Motor frame size
M [mm (in)]
N [mm (in)]
P [mm (in)]
S [mm (in)]
T [mm (in)]
LA [mm (in)]
HA [mm (in)]
HD [mm (in)] without VLT
MH1
MH2
MH3
HD [mm (in)] with VLT
MH1
MH2
MH3
Table 6.6 FCM 106 Dimensions: Flange Mounting - B5, B35 for Asynchronous or PM Motor
62
T LA
C
71 80
130 (5.1) 165 (6.5)
110 (4.3) 130 (5.1)
160 (6.3) 200 (7.9)
M8 M10
3.5 (0.14) 3.5 (0.14)
10 (0.4) 10 (0.4)
HA = AC1 + height of the frequency converter.
For frequency converter dimensions, see Table 6.4.
®
PROFIBUS DP MCA 101
247 (9.7) 267 (10.5)
248 (9.8) 268 (10.6)
– –
®
PROFIBUS DP MCA 101
262 (10.3) 282 (11.1)
263 (10.4) 283 (11.2)
– –
Danfoss A/S © 06/2016 All rights reserved.
®
VLT DriveMotor FCP 106/FCM 106
90S 90L
165 (6.5) 165 (6.5)
130 (5.1) 130 (5.1)
200 (7.9) 200 (7.9)
M10 M10
3.5 (0.14) 3.5 (0.14)
12 (0.5) 12 (0.5)
286 (11.3) 286 (11.3)
287 (11.4) 287 (11.4)
299 (11.8) 299 (11.8)
301 (11.9) 301 (11.9)
302 (11.9) 302 (11.9)
314 (12.4) 314 (12.4)
100L 112M 132S
215 (8.5) 215 (8.5) 265 (10.4)
180 (7.8) 180 (7.8) 230 (9.1)
250 (9.8) 250 (9.8) 300 (11.8)
M12 M12 M12
4 (0.16) 4 (0.16) 4 (0.16)
14 (0.6) 14 (0.6) 14 (0.6)
– – –
304 (12) 332 (13.1) –
316 (12.4) 244 (9.6) 379 (14.9)
– – –
319 (12.6) 347 (13.7) –
331 (13.1) 359 (14.1) 394 (15.5)
MG03M202
