System Integration
equipment in a cabinet with fresh air ventilation, keeping
aggressive gases away from the frequency converter.
Before installing the frequency converter, check the
ambient air for liquids, particles, and gases. These checks
are done by observing existing installations in this
environment. Typical indicators of harmful airborne liquids
are water or oil on metal parts, or corrosion of metal parts.
Excessive dust particle levels are often found on instal-
lation cabinets and existing electrical installations. One
indicator of aggressive airborne gases is blackening of
copper rails and cable ends on existing installations.

3.6.5 Ambient Temperature

For recommended ambient temperature during storage
and operation, refer to chapter 6.5 Ambient Conditions and
chapter 6.10 Derating According to Ambient Temperature and
Switching Frequency.

3.6.6 Acoustic Noise

FCP 106
Acoustic noise originates from the sources:
•
External fan.
•
DC intermediate circuit coils.
•
RFI filter choke.
Switching frequency MH1
[kHz] [dB]
5 55
Table 3.15 FCP 106 Acoustic Noise Levels, Fan on,
Measured 1 m from the Unit
FCM 106
Acoustic noise originates from the sources:
•
Motor fan.
•
External fan.
•
Motor stator and rotor.
•
DC intermediate circuit coils.
•
RFI filter choke.
Motor Switching
speed frequency Fan
[RPM] [kHz] [on/off]
0 5 on
150 5 off
150 5 on
1500 5 off
1500 5 on
1500 10 off
MG03M202
Design Guide
MH2 MH3
[dB] [dB]
55.5 52
MH1 MH2 MH3
[dB] [dB] [dB]
55 55.5 52
57.5 50 57
61 57 59
65.5 64 71.5
66 65.5 71.5
65 61.5 66.5
Danfoss A/S © 06/2016 All rights reserved.
Motor Switching
speed frequency Fan
[RPM] [kHz] [on/off]
1500 16 off
1500 16 on
Table 3.16 FCM 106 Acoustic Noise Levels,
Measured 1 m from the Unit

3.6.7 Vibration and Shock

The frequency converter complies with requirements for
wall- or floor-mounted units mounted at production
premises, as well as in panels bolted to walls or floors.
The frequency converter has been tested according to the
procedures defined in Table 3.17.
IEC 61800-5-1 Ed.2 Vibration test, Cl. 5.2.6.4
IEC/EN 60068-2-6 Vibration (sinusoidal) - 1970
IEC/EN 60068-2-64 Vibration, broad-band random
IEC 60068-2-34, Curve D (1–3) Long-term test 2.52 g
60068-2-35, 60068-2-36 RMS
Table 3.17 Vibration and Shock Test Procedure Compliance
MH1 MH2 MH3
[dB] [dB] [dB]
64 60 65.5
64.5 62 65.5
