System Integration
Motor size
3 3
71
90
112
132 M
132 XL
132 XXL
Table 3.7 Permissible Forces, HPS Motors
Permissible radial forces: Load point corresponding to half-shaft extension, 0 axial force assumed.
Permissible axial forces: 0 radial force assumed.
Permissible loads of simultaneous radial and axial forces can be supplied on request.
Motor type
Asynchronous
PM
Table 3.8 Lubrication
Motor frame
size
71
80
90
100
112
132
160
180
Table 3.9 Standard Bearing References and Oil Seals for Motors
1) Data available at future release.
36
Permissible radial
HPS motors
20000 h
Speed
F rad [N]
[RPM]
1500 580
1800 520
3000 460
3600 415
1500 940
1800 845
3000 670
3600 600
1500 1300
1800 1170
3000 930
3600 835
1500
1800 1710
3000 1350
3600 1215
1500 1970
1800
3000 1400
3600 1260
1500 1970
1800 1770
3000 1400
3600 1260
Motor frame size
80–180
71–160
Speed Bearing type, asynchronous motors
[RPM]
Drive end
1500/3000 –
1500/3000 6204 2ZC3
1500/3000 6205 2ZC3
1500/3000 6206 2ZC3
1500/3000 6306 2ZC3
1500/3000 6208 2ZC3
1500/3000
1)
1500/3000
1)
