Danfoss VLT DriveMotor FCP 106 Design Manual page 35

System Integration
1
2
3
4
5
6
9
7
8
1 Frequency converter cover
2 Frequency converter enclosure
3 Motor connector
4 Motor connector gasket
5 Motor adapter plate
6 Gasket between motor and motor adapter plate
7 Dust seal drive end
8 Flange end shield
9 Bearing
10 Snap ring
11 Stator frame
Illustration 3.4 FCM 106 with PM Motor, B5 Exploded View
MG03M202
Design Guide
14
13
12
11
10
12
13
14
15
16
17
18
19
20
21
22
Danfoss A/S © 06/2016 All rights reserved.
22
20
16
15
17
9
Fixing bolt end shield drive end
Shaft key
Rotor
Snap ring
Pre-load washer
End shield non-drive end
Fixing bolt end shield non-drive end
Fan
Fan cover
Fan cover screw
LCP
3
21
19
18
33
3
