5 Type Code and Selection Guide

5.1 Drive Configurator

Configure a frequency converter according to the
application requirements, using the ordering number
system.
Order frequency converter motors as standard or with
internal options by using a type code string, for example:
5 5
FCM106P4K0T4C55H1FSXXANXE4N4K0150B03000
Refer to chapter 5.2 Type Code String for a detailed specifi-
cation of each character in the string. In the example
above, a motor with efficiency class IE4 and with a normal
overload load profile is included in the frequency
converter. Ordering numbers for frequency converter
motor standard variants are available in
chapter 5.3 Ordering Numbers.
To configure the correct frequency converter or frequency
converter motor for an application, and generate the type
code string, use the internet-based Drive Configurator. The
Drive Configurator automatically generates an 8-digit sales
number to be delivered to the local sales office.
Furthermore, it can produce a project list with several
products and send it to a Danfoss sales representative.
To access the Drive Configurator, go to: www.danfoss.com/
drives.
