Abbreviations

The following abbreviations are used in this manual:
AC alternating current
atm pressure unit (atmosphere)
barg pressure unit (=100 kP or 0.987 atm) gauge
°C degrees Celsius
°F degrees Fahrenheit
DC direct current
dp dew point
EU European Union
g/m grams per cubic meter
3
HCdp hydrocarbon dew point
IEC International Electrotechnical Commission
kg kilogram
lb pound
lbs/mmscf pounds of water per million standard cubic feet of gas
m meter(s)
mA milliampere
max maximum
mg/m milligrams per cubic meter
3
mm millimeters
mV millivolts
Nl/min normal liters per minute
Nm /hr normal cubic meters per hour
3
% percentage
ppm parts per million by volume
V
psig pounds per square inch
RS232 serial data transmission standard
RS485 serial data transmission standard
RTU Remote Terminal Unit
scfh standard cubic feet per hour
temp temperature
V Volts
W Watts
Wdp water dew point
Ω Ohms
" inch(es)

Warnings

The following general warnings listed below are applicable to this instrument. They are
repeated in the text in the appropriate locations.
viii
Where this hazard warning symbol appears in the following
sections it is used to indicate areas where potentially
hazardous operations need to be carried out.
Where this symbol appears in the following sections it is
used to indicate areas of potential risk of electric shock.
Condumax II User's Manual
97081 Issue 28.1, July 2018
