APPENDIX E
06 Write to Single Register
This function code is used to write a 16 bit value into a single register, and the master
specifi es the address and the value to be written. The fi gure below shows the state
diagram of how the message is processed with the exceptions that may be raised.
ENTRY
Exception Code = 01
70
Address in message = Instrument Address
Function code supported
0x0000 <= Register Value<= 0xFFFF
Exception Code = 03
Exception Code = 02
Exception Code = 04
Sends Exception Response
Write Single Register State Diagram
Figure 30
Condumax II User's Manual
Register Address == OK
Request Processing
Write To Single Register = OK
Mirrors Request
EXIT
