APPENDIX E
E.3

Exceptions

A message request from the master will raise an exception response from the slave
(Condumax) if:
• the function code is unsupported
• the register quantity > 127 (0x007D)
• the register address is invalid
• the register address + the quantity of register is invalid
• an error occurred while performing the function
The exception response will contain the function code incremented by 80H and the
exception code.
The table below lists the codes supported along with an explanation of each code:
Code
01
02
03
04
Example of an Exception Response that reads a discrete inputs
Byte
1
2
3
4
The example above shows that the function code (02H) sent in the request has been
incremented by 80H with the exception code 01H included as the data within the
message.
