Engine Control System Flow Diagram
28
23
19
20
18
14
13
15
16
1. Flywheel
2. CKP sensor
3. Ex. manifold temp. sensor
4. Cylinder temp. sensor
5. Spark plug
6. Ignition coil
7. CMP sensor
8. MAP sensor
9. Throttle position sensor
10. IAT sensor
29
21
17
12
11. IAC valve
12. PTT switch
13. ECM main relay
14. Ignition switch
15. Fuse (30 amp.)
16. Fuse (15 amp.)
17. Starter relay
18. Neutral switch
19. Trim/Tilt sensor
20. Shift position sensor
Engine General Information and Diagnosis:
30
32
22
33
37
27
11
26
25
10 9
21. PTT relay
22. PTT motor
23. Battery
24. Fuel injector
25. Air intake silencer
26. Throttle body
27. Intake manifold
28. Fuel tank
29. Fuel primer bulb
30. Low pressure fuel filter
1A-3
2
35
1
34
31
36
6
7
24
8
3
4 5
I9J011110002-04
31. Low pressure fuel pump
32. Fuel vapor separator
33. Float
34. High pressure fuel pump
35. High pressure fuel filter
36. Fuel cooler
37. Fuel pressure regulator
