Suzuki DF70A Service Manual page 43

Anodes Inspection
Inspect anodes
Every 50 hours (3 months)
If 2/3 of zinc anode has corroded away, replace anode.
The anode should be periodically cleaned with a wire
brush to ensure maximum effectiveness.
CAUTION
Never paint the anode.
NOTE
The anode cover (1) may be separated from
the power unit body by inserting and turning
a 10 mm bolt (2) to function as a screw jack.
2
1
NOTE
The anode (3) securing bolt should be
covered with suzuki silicone seal.
: Sealant 99000–31120 (SUZUKI Silicone Seal
(50 g))
3
Z9J0110206048
I9J011020022-04
NOTE
To access the anode in the gearcase, remove
the water inlet filter.
I9J011020023-01
Maintenance and Tune-Up:
1
1
1
3
0B-17
I9J011020057-01
I9J011020058-01
I9J011020025-02
3
I9J011020026-02
