3A-22 Right Hand Rotation Unit:
• Apply water resistant grease to the shift rod guide
housing O-ring.
: Grease 99000–25161 (SUZUKI Water
Resistant Grease (250 g))
NOTE
Before installing the shift rod guide housing
assembly, bring the shifter yoke to the
"Neutral" position by turning the shift rod
right or left.
• Install the shift rod guide housing assembly (9) by
aligning the shifter yoke with the groove in the
connector pin, then tighten the housing bolt (10)
securely.
I9J011310098-01
• Turn the shift rod from the "Neutral" position to the
"Forward" and "Reverse" position to check proper
gear engagement.
Leakage Check
Check for leakage of oil seal and O-ring when applying
specified pressure inside of the gearcase.
I9J011310100-01
1) Install the test tool into the oil level hole.
2) Connect the air pump to the tester.
9
I9J011310101-02
10
9
I9J011310102-01
