Suzuki DF70A Service Manual page 21

Starter Motor
Item
Max. continuous time of use
Motor output
Brush length
Commutator undercut
Commutator outside diameter
PTT Motor
Item
Brush length
Commutator outside diameter
Self-Diagnostic Code
0: OFF, 1: ON
Failed item
MAP sensor 1
Cylinder temp. sensor
IAT sensor
CKP sensor
CMP sensor
Air intake system
MAP sensor 2
Exhaust manifold temp. sensor
Fuel injector
Throttle position sensor
Shift position sensor
Neutral switch
Unit
Sec.
kW
std. mm (in.)
Limit mm (in.)
std. mm (in.)
Limit mm (in.)
std. mm (in.)
Limit mm (in.)
Unit
std. mm (in.)
Limit mm (in.)
std. mm (in.)
Limit mm (in.)
Code
3 – 4
1 – 4
2 – 3
4 – 2
2 – 4
2 – 2
3 – 2
1 – 5
4 – 3
2 – 1
1 – 2
3 – 3
General Information:
Data
DF70AT DF80AT
30
1.4
16.0 (0.63)
12.0 (0.47)
0.5 – 0.8 (0.02 – 0.03)
0.2 (0.01)
29.0 (1.14)
28.0 (1.10)
Data
DF70AT DF80AT
9.8 (0.39)
5.5 (0.22)
22.0 (0.87)
21.0 (0.83)
Lamp flashing pattern
1
0
MCODE00D34-0-01
1
0
MCODE00D14-0-01
1
0
MCODE00D23-0-01
1
0
MCODE00D42-0-01
1
0
MCODE00D24-0-01
1
0
MCODE00D22-0-01
1
0
MCODE00D32-0-01
1
0
MCODE00D15-0-01
1
0
MCODE00D43-0-01
1
0
MCODE00D21-0-01
1
0
MCODE00D12-0-01
1
0
MCODE00D33-0-01
0A-12
DF90AT
DF90AT
Fail-safe system
activating
YES
YES
YES
NO
NO
YES
NO
YES
NO
YES
YES
NO
