Suzuki DF70A Service Manual page 16

0A-7 General Information:
Item
Engine oil
Engine oil amounts
Gear oil
Gearcase oil capacity
Bracket
Item
Trim angle
Number of trim position
Maximum tilt angle
Lower unit
Item
Reversing system
Transmission
Reduction system
Gear ratio
Drive line impact protection
Propeller shaft rotation (when shift into
forward)
Propeller
Reduction system
Item
1st reduction gear ratio
(Crankshaft drive gear: Driven gear)
2nd reduction gear ratio (Lower unit gear)
Total reduction gear ratio
Unit
DF70AT
• API classification: SG, SH, SJ, SL, SM or NMMA FC-W
classification: SG, SH, SJ, SL, SM
• Viscosity rating: SAE 10W-40 or NMMA FC-W 10W-40
L (US/lmp. qt)
SUZUKI Outboard Motor Gear Oil or SAE 90 hypoid gear oil, API
classification GL-5.
ml (US/lmp. oz)
Unit
DF70AT
degree
degree
Unit
DF70AT
Unit
DF70AT
Data
DF80AT
4.0 (4.2 / 3.5): Oil change only
4.3 (4.5 / 3.8): Oil filter change
850 (28.7/30.0)
Data
DF80AT
0 – 20 (–6 to 14)
PTT system
75 (–6 to 69)
Data
DF80AT
Gear
Forward-Neutral-Reverse
Bevel gear
12 : 25 (2.08)
Spline drive rubber hub
Clockwise
Blade x Dia. (in.) x Pitch (in.)
3 x 14 x 13
3 x 13 and 7/8 x 15
3 x 13 and 3/4 x 17
3 x 13 and 3/4 x 19
3 x 13 and 3/4 x 21
3 x 13 and 3/4 x 23
3 x 13 and 1/2 x 15
3 x 14 x 17
3 x 14 x 19
3 x 14 x 21
3 x 14 x 23
Data
DF80AT
29 : 36 (1.24)
12 : 25 (2.08)
2.59 (36/29 x 25/12)
DF90AT
DF90AT
DF90AT
DF90AT
