0A-1 General Information:
General Information
General Information
Symbols
Listed in the table below are the symbols indicating instructions and other important information necessary for proper
servicing.
Please note the definition for each symbol. You will find these symbols used throughout this manual.
Refer back to this table if you are not sure of any symbol (s) meanings.
Symbol
Torque control required.
Data beside it indicates specified torque.
Apply oil.
Use engine oil unless otherwise specified.
Apply molybdenum oil solution.
(Mixture of engine oil and SUZUKl MOLY PASTE in a ratio of 1 : 1)
Apply SUZUKI Outboard Motor Gear Oil.
Apply SUZUKI Super Grease A.
Apply SUZUKI Moly Paste.
99000-25140
Apply SUZUKI Water Resistant Grease.
Apply SUZUKI Bond 1207B.
Apply SUZUKI Silicone Seal.
Apply SUZUKI Thread Lock 1342.
Apply SUZUKI Thread Lock Super 1333B.
Use special tool.
Do not reuse.
Note on reassembly.
Use peak voltmeter Stevens CD-77.
Abbreviations
Abbreviations used in this service manual are as follows:
A:
ATDC: After Top Dead Center
AC: Alternating Current
B:
BTDC: Before Top Dead Center
C:
CKP Sensor: Crankshaft Position sensor
CMP Sensor: Camshaft Position sensor
CTP: Close Throttle Position
D:
DC: Direct Current
DOHC: Double Over Head Camshaft
E:
ECM: Engine Control Module
EX (Ex.): Exhaust
F:
FP: Fuel Pump
G:
GND: Ground
General Description
Definition
I:
Z9J0110101002
IAC: Idle Air Control
IAT: Intake Air Temperature
IG: Ignition
Ign.: Ignition
IN (In.): Intake
L:
LPS: Lever Position Sensor
M:
MAP: Manifold Absolute Pressure
P:
PCV: Positive Crankcase Ventilation
PORT: Port
PTT: Power Trim and Tilt
S:
SPS: Shift Position Sensor
STBD: Starboard
SIGP: Start-In-Gear Protection
T:
TPS: Throttle Position Sensor
Z9J0110101001
