Cytek Biosciences Aurora User Manual page 34

The following table describes the controls in the Acquisition Control pane.
No. Control
1 Start/Record/Stop/
Restart
2 Flow Rate
3 Events Rate, Abort
Rate, Threshold
Count, Time Elapsed
4 Events to Display
Instrument Control
The Instrument Control pane consists of the Gain, Threshold, Signal, and Lasers tabs for use in
adjusting the instrument.
34 Aurora User's Guide
Description
Start and Record are enabled when a tube is present on the SIP.
Select Start to start acquisition
Select Record to record data. Record can also start acquisition.
Select Stop to stop acquisition.
Select Restart to restart the acquisition counters. All events and
results displayed are refreshed.
Stop and Restart are enabled once Start is selected.
Select Low (15 μL/min), Medium (30 μL/min), or High (60 μL/min)
Displays the real-time counts during acquisition.
Enter the number of events you want displayed during
acquisition.
1
2
4
3
