Board Overview

f
Altera Corporation
April 2012
2. Board Components and
This chapter provides operational and connectivity detail for the board's
major components and interfaces and is divided into the following major
blocks:
■
Featured device
■
Clocking circuitry
■
Jumpers
■
Interfaces
USB interface
●
Altera HSMC expansion connector
● ®
General user interfaces
●
■
Memory
■
Power supply
■
Statement of China-RoHS compliance
1
The board schematics, physical layout database, and
manufacturing files for the Cyclone
included in the Cyclone III FPGA Starter Kit in the following
directory:
<install path>\cycloneIII_3c25_start\board_design_files
For information on powering-up the Cyclone III FPGA starter board and
installing the demonstration software, refer to the Cyclone III FPGA
Starter Kit User Guide.
Interfaces
®
III FPGA starter board are
Preliminary
2–1
