• a "Base" setting, which is always available
• a "NewSetting1", which has been derived from "Base".
As "NewSetting1" has been derived from "Base" changing a property in "Base" will automatically change this
property in "NewSetting1" if this property has not already been modified in "NewSetting1". Again to get an
understanding for this behaviour please refer to
• "Working with settings" chapter of the "mvIMPACT Acquire API" manuals.
Now, to set up wxPropView (p. 48) to display all images taken using capture setting "Base" in one display and all
image taken using capture setting "NewSetting1" in another display the capture settings need to be assigned to
image displays via "Capture -
Figure 21: wxPropView - two settings
Capture Settings - Assign To Display(s)".
