8.3 mvHYPERION-HD-SDI
Interface
Bus
Continuous data rate
Peak data rate
Payload size
Current consumption
PCIe 3.3V
PCIe 12V
Camera supply
Environmental conditions
Ambient temperature
Storage temperature
Humidity
Dimensions
Length
Width
MATRIX VISION GmbH
PCI Express® x4
Max. 640 MB/s
Max. 1 GB/s
Up to 256 Bytes
Max. 1A
Max. 0.05A + camera power
Via PCI Express® 12V fused
0 up to 45 C
-20 up to 70 C
10 up to 90 % non-condensing
155 mm
111.1 mm
