IDC multi-pin connector 2 x 10 Pol RM 2.54 x 2.54 mm.
Note
Pins are not opto-isolated, feature no EMC filter and are not protected against overload and overvoltage.
Digital signals (pins 9-16) are LVTTL signals and not 5V tolerant. Failure to take this into account may
result in the destruction of the board.
Attention
Without an additional card with corresponding snubbers these signals must not conducted!

8.3.3 Components

supported signal formats
mvHYPERION
-HD-SDI-2
