8.1 mvHYPERION-CLx
VIH, 3.9V...2.0V
max..min:
VIL, 0.8V...-0.3V
max..min:
IOL, max: 0.5V
IL, max: 3.5V

8.1.3 Components

mvHYPERION
-CLb
Video input
Signal format CameraLink ™ (MiniCL)
Video input 1x BASE
Max. CL clock 85 MHz
Supported CL 1.2
specification
Resolution
Horizontal / vertical 64 K / not limited
Pixel formats
RGB 24 / 30 / 32 bit
Gray 8 / 10 / 12 / 14 / 16 bit
Interface
Bus PCI Express® x1
Continuous data Max. 200 MB/s
rate
Peak data rate Max. 250 MB/s
Payload size Up to 512 Bytes
Digital in and out-
puts
Trigger-In 1, differential, opto-
isolated, 5 to 24V
Strobe-Out 1, differential, opto-
isolated, max. 30V,
100mA
Sync-In 1, differential, opto-
isolated, 5 to 24V
Current consump-
tion
PCIe 3.3V Max. 1A
PCIe 12V Max. 0.05A + camera power
Camera supply Via PCI Express® 12V max. 0.7A fused
Via additional floppy power plug up to 2A
Environmental con-
ditions
