8.1 mvHYPERION-CLx
8.1.2.9.1 Opto-isolated digital inputs
TTL compatible threshold (standard):
VIH, 25V
max:
VIH, 4V
min:
VIH, typ 5V..24V
VIL, max 1V
VIL, min -30V
Ii, max 20mA
PLC compatible threshold (additionally external protective circuit of Z diodes necessary):
VIH, 37V
max:
VIH, 15V
min:
VIL, max 13V
VIL, min -30V
MATRIX VISION GmbH
Figure 11: Trigger-In mvHYPERION-CLx
Figure 12: Trigger-Out mvHYPERION-CLx
(VIH, max = maximum input voltage, which causes an active signal)
(VIH, min = minimum input voltage, which causes an active signal)
(VIH, typ = typical input voltage, which causes an active signal)
(VIL, max = maximum input voltage, which causes an inactive signal)
(VIL, min = minimum input voltage, which causes an active signal)
(li, max = maximum input current)
(VIH, max = maximum input voltage, which causes an active signal)
(VIH, min = minimum input voltage, which causes an active signal)
(VIL, max = maximum input voltage, which causes an inactive signal)
(VIL, min = minimum input voltage, which causes an active signal)
