8.3 mvHYPERION-HD-SDI
8.3.2.2 Pinning J5 (15-pol D-SUB/HD connector)
Pin Signal
1 Sync-Out 1 (Trilevel, 75R)
2 Sync-Out 2 (Trilevel, 75R)
3 Sync-Out 3 (Trilevel, 75R)
4 ID2
5 Digital Ground RS-485
6 Ground Sync-Out 1
7 Ground Sync-Out 2
8 Ground Sync-Out 3
9 Camera Power Supply
10 Ground Sync
11 ID0
12 RS-485 TRX-
13 C/HSync-Out
14 VSync-Out
15 RS-485 TRX+
8.3.2.3 Pinning J6 (internal digital I/Os)
Pin
1
2
3
4
5
6
7
8
12..9
16..13
17
18
19
20
MATRIX VISION GmbH
Figure 18: J5
Signal direction
OUT
OUT
OUT
IN/OUT
GND
GND
GND
GND
OUT
GND
IN/OUT
IN/OUT
OUT
OUT
IN/OUT
Figure 19: J6
Signal Signal direction
NC -
Ground GND
SCL IN/OUT
Ground GND
SDA IN/OUT
Ground GND
+5V power supply OUT
+3.3V power supply OUT
GPIN3..0 IN
GPOUT3..0 OUT
Ground GND
+12V power supply OUT
+12V power supply OUT
Ground GND
Level
1Vss (75R)
1Vss (75R)
1Vss (75R)
TTL (open collector)
-
-
-
-
+5VDC / =10W (optional +12VDC)
-
TTL (open collector)
RS485-
TTL (push pull)
TTL (push pull)
RS485+
Level
-
-
LVTTL
-
LVTTL
-
+5V DC
+3.3V DC
LVTTL(3.3V) input.
not 5V tolerant!
LVTTL(3.3V) output.
not 5V tolerant!
-
+12V DC
+12V DC
-
