9.1 wxPropView
When importing a " .raw"
the pixel format of the image. When the file name has been generated using the image storage function offered
by wxPropView (p. 48), the file name will be passed and the extracted information will automatically be set in the
dialog thus the user simply needs to confirm this information is correct.
9.1.1.8 Setting up multiple display support and/or work with several capture settings in parallel
wxPropView (p. 48) is capable of
• dealing with multiple capture settings or acquisition sequences for a single device and in addition to that
• it can be configured to deal with multiple image displays.
For frame grabbers with multiple input channels this e.g. can be used to display live images from all input channels
simultaneously. This even works if each input channel is connected to a different video signal in terms of resolution
and timing.
The amount of parallel image displays can be configured via the command line parameter (p. 94)
. In this step by step setup wxPropView (p. 48) has been started like this from the command line:
"dcy"
wxPropView dcx=1 dcy=2
This will result in 1 display in horizontal direction and 2 in vertical direction.
MATRIX VISION GmbH
image file a small dialog will pop up allowing the user to define the dimensions and
Figure 16: wxPropView - Raw image file import
59
"dcx" and
