Ii, max 20mA
Max. input frequency of the opto-isolated inputs: 10MHz
An additional series resistor is not necessary at the inputs. The inputs own an internal current limitation and are
protected up to -30V against polarity.
8.1.2.9.2 Opto-isolated digital output
Attention
The output is not overload protected and doesn't feature a free-wheeling diode!
There are following conditions:
VCEO, max 35V
(typ):
VECO, max: 0.3V
VCE, sat 1.5V
IC, max 200mA
tr, max 5us
tf, max 2ms
tf, max 20us
The output is not protected against overvoltage, overload and polarity reversal.
8.1.2.10 Digital I/Os (J6)
8.1.2.10.1 LVTTL-IN parameters (GPIN3..0)
VIH, 3.9V...2.0V
max..min:
VIL, 0.8V...-0.3V
max..min:
Iin, max:
8.1.2.10.2 LVTTL-OUT parameters (GPOUT3..0 and I2C-SCL)
OH, 2.4V
min:
OL, 0.4V
max:
Iout, 4mA
max:
8.1.2.10.3 LVTTL-OC parameters (I2C-SDA)
(li, max = maximum input current -
(VCEO, max = max. voltage between C (pin 2) and E (pin 3) on opened transistor)
(VCEO, max = max. voltage between E (pin 3) and C (pin 2) on opened transistor)
(VCE, sat = max. voltage between C (pin 2) and E (pin 3) on active transistor and
IC, max)
(IC, max. = max. current which is allowed to flow to the direction of C (pin 2))
(rise (on) time)
(fall (off) time HW rev. 1.xx)
(fall (off) time HW rev. 2.00)
(VIH, max = permissible input voltage, which causes an active signal)
(VIL, max = permissible input voltage, which causes an inactive signal)
0,1mA (Iin,max = maximum input current)
(OH, mix = minimum active output voltage with Iout = -2mA output current)
(OL, max = maximum inactive output voltage with Iout = +2mA output current)
(Iout, max = maximum output current)
controlled internally)
