Manufacturer of the connector: Nexus
Part No.: 32040168R
8.2.2.3 Audio
Both audio connectors (left and right) are Cinch connectors.

8.2.3 Components

6 VIDEO_13
7 VIDEO28 Not used
8 VIDEO_12
9 VIDEO27 Not used
10 VIDEO_11
11 VIDEO26 Not used
12 VIDEO_10
13 VIDEO25 Not used
14 VIDEO_9
15 VIDEO24 Not used
16 VIDEO_8
17 VIDEO23 Not used
18 VIDEO_7
19 VIDEO22 Not used
20 VIDEO_6
21 VIDEO21 Not used
22 VIDEO_5
23 VIDEO20 Not used
24 VIDEO_4
25 VIDEO19 Not used
26 VIDEO_3
27 VIDEO18 Not used
28 VIDEO_2
29 VIDEO17 Not used
30 VIDEO_1
31 VIDEO16 Not used
32 VIDEO_0
33 RS-485 TXP
34 RS-485 RXP
Video
Input signal
50Hz
60Hz
Number of video inputs
40 GND (G)
41 GND (G)
42 GND (G)
43 GND (G)
44 GND (G)
45 GND (G)
46 GND (G)
47 GND (G)
48 GND (G)
49 GND (G)
50 GND (G)
51 GND (G)
52 GND (G)
53 GND (G)
54 GND (G)
55 GND (G)
56 GND (G)
57 GND (G)
58 GND (G)
59 GND (G)
60 GND (G)
61 GND (G)
62 GND (G)
63 GND (G)
64 GND (G)
65 GND (G)
66 GND (G)
67 RS-485 TXN
68 RS-485 RXN
mvHYPERION
-32R16
Interlaced, gray scale
Interlaced, color
PAL
NTSC
32
