8.3.2 Connectors

8.3.2.1 Use of J1..J2
Figure 16: mvHYPERION-HD-SDI-2 block diagram
Figure 17: mvHYPERION-HD-SDI-2
Connector usage
mvHYPERION
-HD-SDI-2
J1
Camera 1 (3G/HD-SDI signal)
J2
Camera 2 (3G/HD-SDI signal)
