Technical Specifications

2. Technical Specifications
Electrical Characteristics
Power Supply Type
Operating Voltage Range
Absolute Maximum
(non-operating)
Input Current
Tamper Output
Maximum Cable Distance to
Controller
Card Output Format
Max. Proximity Card Read
Range*
Environmental Characteristics
Operating Temp. Range
Operating Humidity Range
Physical Characteristics
Dimensions (H x W x D)
Weight
* Measured using a Rosslare proximity card or equivalent. Range also depends
on electrical environment and proximity to metal.
8
Linear type (recommended)
5 to 16 VDC
18 VDC
Standby: 120 mA
Read: 140 mA
Open collector, active low, max. sink
current 30 mA
150 m (500 ft)
Wiegand 26-Bit
22 cm (9 in.)
-32°C to 63°C (-25°F to 145°F)
0 to 95% (non-condensing)
Suitable for outdoor use (IP54)
125 x 125 x 21 mm
(4.9 x 4.9 x 0.8 in.)
285 g (10.1 oz)
