Technical Specifications

2. Technical Specifications
Electrical Characteristics
Power Supply Type
Operating Voltage Range
Input Current Standby (12 VDC) 110 mA
Input Current Max (16 VDC)
LED Control Input
Tamper Output
Cable Distance to Host
Controller
Max. Proximity Card Read
Range*
Proximity Card Modulation
Proximity Card Compatibility
Card Transmit Format (Reader) Rosslare proximity cards: Wiegand 26-bit,
Keypad Transmit Format
(Reader)
LED Indicators
Communication
* Measured using a Rosslare proximity card or equivalent. Range also
depends on electrical environment and proximity to metal.
AYC-E/Q60 Series Installation and Programming Manual
Linear (recommended)
E/T: 6–16 VDC
Q: 5–16 VDC
(when used as a controller, provided by
the secured intelligent power supply)
130 mA
Dry contact N.O.
Open collector, active low, 32 mA max
sink current
Up to 150 m (500 ft) using an 18-AWG
cable
Rosslare proximity: E – 40 mm (1.57 in.), Q
– 45 mm (1.77 in.), T – 40 mm (1.57 in.)
HID Prox: E – 40 mm (1.6 in.), Q – 45 mm
(1.8 in.), T – 30 mm (1.2 in.)
Rosslare proximity/HID Prox at 125 kHz
Rosslare proximity/HID Prox cards
or Clock & Data
HID cards: According to card type
Programmable PIN code formats
Two tri-colored LEDs
Data1/C1, Data0/C2–open collector,
5 V termination
