Installation
The reader must be mounted with the appropriate screws (not
supplied), as described in the template provided.
To install the reader:
1. Determine an approximate location for the installation of the
reader.
2. Peel off the back of the self-adhesive installation label template
and locate it at the required location.
3. Using the template as a guide, drill two holes (the size of which
are indicated in the template) to install the reader onto the
surface.
4. Drill a 10-mm (
installing the reader on metal, place a grommet or electrical tape
around the edge of the hole.
5. Route the interface cable from the reader to the controller. A
linear type power supply is recommended.
The reader can also be mounted using strong epoxy glue. After
application, the reader should be firmly held in place until the
glue dries.
10
7
/ ") hole for the cable. In the event that you are
