Connect the Cables to the Board & PC
Connect the
Cables to the
Board & PC
Figure 2–2. Connecting the USB Blaster Cable to J21
2–8
DSP Development Kit, Stratix II Edition Getting Started User Guide
The instructions in this section explain how to set up the following
hardware:
■
USB Blaster cable
■
Power supply cable
■
SMA cable
■
SLP-50 anti-aliasing filter
USB Blaster Cable
Connect the USB Blaster cable's 10-pin female plug to the Stratix II device
JTAG header on the Stratix II EP2S60 DSP development board (J21) and
connect the other end to your PC to configure the Stratix II device directly
using an SRAM Object File (.sof). See
and lab provided with this kit include SOFs for configuring the Stratix II
device directly.
Development Kit Version 1.1.0
Figure
2–2. The reference designs
Altera Corporation
May 2005
