Getting Started
Altera Corporation
May 2005
When you have finished installing DSP Builder, view DSP Builder
libraries in the MATLAB software by performing the following steps.
a. Start the MATLAB software.
5. At the MATLAB command prompt, change directory to the DSP
Builder\altlib directory and type the following:
setup_dspbuilder r
6. Expand the Simulink icon in the MATLAB Launch Pad window.
7. Double-click the Library Browser icon. The Altera DSP Builder
folder appears in the Simulink Library Browser window.
Refer to the DSP Builder User Guide for information on the DSP Builder
directory structure. The DSP Builder User Guide also includes a tutorial
that describes how to create a design in Simulink and then convert it to
VHDL for synthesis, Quartus II compilation, and RTL simulation.

Installing the Nios II Embedded Processor

The Nios II CPU component and integrated development environment
may be installed from the CD-ROM included in the kit.
1. Insert the Nios II Embedded Processor Windows version 5.0 CD-ROM.
®
If the install program does not automatically start, browse to your
CD-ROM drive and double-click on the program launcher.exe.
2. Select which components to install. It is recommended that you
install the default check box options.
3. Follow the on-screen instructions to select the installation directory
and program group.
Development Kit Version 1.1.0
DSP Development Kit, Stratix II Edition Getting Started User Guide
2–5
