Software Installation
f
2–4
DSP Development Kit, Stratix II Edition Getting Started User Guide
6. Select Typical or Custom installation and click Next.
7. Click Install.
8. Click Finish.

Install DSP Builder

To install DSP Builder on a PC running Windows NT/2000/XP, perform
the following steps.
1
Before you install DSP Builder, Altera recommends that you
install the MATLAB and Simulink software and the Quartus II
software.
1. Close the following software applications if they are open:
The Quartus II software
●
The MAX+PLUS
●
The LeonardoSpectrum™ synthesis tool
●
The Synplify software
●
The ModelSim simulator
●
The Precision RTL Synthesis software
●
2. Choose Run (Windows Start menu).
3. Type <drive letter>:\DSPBuilder.exe, where <drive letter> is your
CD-ROM drive.
4. Click OK. The DSPBuilder v5.0 - InstallShield Wizard dialog box
appears. Follow the on-line instructions to finish installation.
1
DSP Builder launches the LeonardoSpectrum, Synplify,
Precision RTL Synthesis, or Quartus II software by retrieving
the software's path information from your PC's registry file. If
you have installed multiple versions of these software products,
the registry may not point to the version you want to use with
DSP Builder. In DSP Builder you can specify a path to use other
than the registry setting for each of the tools.
Refer to Specifying LeonardoSpectrum, Synplify & Quartus II Path
Information for SignalCompiler in the DSP Builder User Guide for
information on specifying the paths.
Development Kit Version 1.1.0
II software
®
