Installing an Optional Sensor Unit

Fixed by screwE: Remove the seal covering screw holes on the bezel. Secure the unit with the attached screw.
Set the sensor unit close to the back side.
Fixed by double-sided tapeE: You can set the sensor unit on any side of the monitor.

NOTEE: For the UX552E:

• When installing the sensor unit on the upper side of the monitor, please use the provided double-sided tape. If the
sensor unit is installed using a screw, it could damage the monitor.

F or the UX552SE:

• Please use double-sided tape only.


Set the sensor unit 8 mm away from the front edge.
Seal
8 mm
Double-sided tape
Screw Position
English−16
