10.2 Command Set
Other printable characters may be typed in as seen on a keyboard.
10.2.3

Broadcast Mode Commands

Broadcast Mode – INTERROGATE (Broadcast OFF)
Command: B0, O0
B0 deactivates the RS-232C broadcast mode (resets to interrogate mode) on the main RS-232 port.
O0 deactivates the RS-232C broadcast mode on the option RS-232 port.
C
Response:
Broadcast Mode – ASCII STD
Command: B1, O1
B1 configures the clock to broadcast the time-of-day as ASCII standard data from the main RS-232
port. O1 configures the clock to broadcast ASCII standard data from the option RS-232 port.
Response: <soh>ddd:hh:mm:ss
Broadcast Mode – VORNE STD
Command: B2, O2
B2 configures the clock to broadcast data formatted for Vorne large format time displays from
the main RS-232 port. O2 configures the clock to broadcast from the option RS-232 port Vorne-
formatted data. Refer to Arbiter Systems Application Note 103 for more information on using
large format displays with GPS clocks from Arbiter Systems.
Response: 44hhmmss
C
55ddd
C
11nn
bel (bel = Hex 07; sounds at the end of the time code)
The number and order of strings returned depend upon options ordered with clock (for example
Option 28):
Data is transmitted ahead of time, and the bel character is transmitted on time. When properly
configured, the Vorne displays update simultaneously upon receipt of the bel character.
Decimal Hex
0 00
1 01
7 07
10 0A
13 0D
Table 10.4: Short Table of ASCII Characters
C
C
(UTC/Local Time)
(day of year)
(out-of-lock time)
Abbreviation Description
NUL Null Character
SOH Start of Header
BEL Bell (sound)
LF Line Feed
CR Carriage Return
69
