C.14 Option 32/33: Internal NTP Server – Obsoleted by Opt34
telnet 192.168.0.232 1
c) Open a telnet connection to port 9999 and set all required parameters.
telnet 192.168.0.232 9999
NOTE: The temporary IP address is reverted after every power reset of the NTS. Be sure to
enter the configuration and store the parameters to make the changes permanent.
After making a connection to configure the NTP server (either through the Ethernet or RS-232
port), the screen should display the top four lines; to enter the Setup Mode, you must press Enter
on the terminal (pc).
*** NTS ***
MAC address 00204AAB5E8A
Software version V5.8.13.RC2 (050126) CPK 580 M100
Press Enter to go into Setup Mode
*** basic parameters
Hardware: Ethernet TPI
IP addr 192.168.0.232, no gateway set
*** Security
SNMP is
SNTP Community Name:
Telnet Setup is
TFTP Download is
Port 77FEh is
ECHO is
*** NTS parameters
Antenna Type: GPS/Arbiter
Encryption is disabled
Sending UDP datagram to Port 024C(hex) every 000 minutes
Send UDP datagram to:
Change Setup:
0 Basic configuration
1 NTS configuration
6 Security
7 Factory defaults
8 Exit without save
9 save and exit
Serial
An ASCII terminal or PC with a terminal emulation can be connected to the option RS-232 port,
but JMP2 and JMP3 must be set to "C" (for Ethernet Port 1) or "D" (for Ethernet Port2), and
JMP4 set to "B". The terminal (or PC) should be configured to 9600 Baud, 8 data-bits, 1- stop
bit, no parity. The power must be cycled to enter the configuration mode. The self-test begins
after power-up. About a half-second later the Error (red) LED starts blinking. Now send three
enabled
public
enabled
enabled
enabled
enabled
Your choice ?
135
